Page #4 background imageLoading...
Page #4 background image
3
B
A
C
D
J
F
I
H
G
E
Diagram and Parts List
A. Spray Head
B. Faucet Body
C. Deck & Putty Plate
D. Base
E. Spray Hose
F. Supply Hose
G. Hot & Cold Waterlines
H. Weight
I. Quick Connect
J. Hex Wrench Set
J1. 2.5mm
J2. 4mm
