Introduction ..................................................................................................................... 9
Scope of supply ................................................................................................................. 9
The gage at a glance ......................................................................................................... 10
Handling during measurement ......................................................................................... 10
Determining of the minimum value ..................................................................................... 11
Determining of the maximum value ..................................................................................... 11
Display adjustment .......................................................................................................... 11
Tolerance marks .............................................................................................................. 12
Spare parts / Accessories ................................................................................................. 12
Warranty ......................................................................................................................... 14
Technical data (mm + inch gages) ..................................................................................... 27
We thank you very much for your confidence in purchasing this product.
This measuring gage is manufactured with high precision parts and carefully assembled.
Therefore never try to disassemble or change any of the interior parts of this gage.
Do not modify the measuring arms. Do not drop or shock this gage.
Protect gage against high temperature, humidity, dust and dirt.
For a better accuracy and repeatability this gage should be used within an operating
temperature of 20 +/-10°C.
This gage is used to measure internal diameters, especially groove diameters. It should only
be used for this purpose. Kroeplin assumes no responsibility for damages caused by
mishandling.
In order to achieve the best use of this measuring instrument it is most important
that you first read the operating instructions and have it ready to hand.
• Measuring gage
• Operating instructions
• Certificate of quality
