Kronos H-46 Series - Technical Data

-A4-
3. Technical Data
Model number
H-46A-12
H-46A-16
H-46B-16
H-46B-19
Battery Type
remarks
BOSCH Li-Ion , 18Vdc 4.0Ah
Charging Time
About 40 minutes
(after 20 minutes, approx. 70% charge capacity)
Strapping Speed
5 sec/cycle (Auto)
Strap Width
11-13mm
15-16mm
15-16mm
19mm
Strap Type
PET, PP
Strap Thickness
PP：0.6mm -1.05mm
PET : 0.5mm -1.05mm
PP : 0.75mm - 1.3mm
PET：0.6mm - 1.3mm
Sealing Joint
friction weld
Vibration
7.77m/s^2
Noise emission
sound pressure level: 82dB(A)
sound power level: 92dB(A)
Tension (max)
250 kg (551 lbs)
400kg(881lbs)
Dimensions
(L)×(W)×(H)
358mm × 143mm × 167mm
Weight
4.3 kg (9.5 lbs)
4.4 kg(9.7lbs)
Working Temperature
The ambient temperature should be between -5℃ and 45℃
( 23 ℉ and 113℉)
The best performance is achieved between 15℃ and 20℃
(59℉ and 68℉)
Remarks:
If the tool will be idle for a long time, be sure to take out the battery to avoid reducing the
battery's life span.
