Chapter 1 Introduction
1-8 Kronos Incorporated
Modem Option Board
You can install an optional modem board in the Series 400 terminal. Two modem
boards are available: the 2400 option board and the high-speed (14.4Kbps) option
board. Each of these option boards makes it possible to establish communications
over telephone lines between the host and the Series 400 terminal.
The following figure illustrates the high-speed modem option board and its
connectors:
Legend
1 RJ-11 jack for the telco cable
2 Mainboard connector (P1)
