22
Owner’s manual
EN
Mounting
User can place the projector at a shelf, or using one of the two threads at the bottom of the
device.
slight angle (front in relation to back). Do not install the device vertically nor at an angle. Do not
place any objects on the projector not around it in close vicinity.
way. If mounted on a mount or a tripod, make sure the mount/tripod will hold the weight of
the projector and additional attachments. If mounted upside down, pay special attention to
The device has two threads at the bottom
for mounting:
1. Support base thread: included in
set. Screw the support base into
the thread and adjust the height to
desired level.
Remark: support base can assure
maximum projection angle of 15°.
obtained by projection angle ranges of 0° -
8° when on the support base.
2. Tripod stand thread: tripod not included.
Keystone correction
Keystone correction allows for adjusting projected image in regards of trapezoid distortion.
Such distortion happens because the projector is placed unevenly (both horizontally and
vertically) in relation to wall/projection screen.
Ideally, the center of the image and the projector would be at the same level and perpendicular
to the projected surface. It is suggested to keep the projector vertical with projector screen and
keep it on the same level.
