3 Replacing the LevelControl Basic 2 BC Control Unit
9 of 12
Compacta / mini-Compacta
Table3: Control unit: Navigation keys
Key Description
Arrow keys (up/down):
▪ Move up/down in the menu options.
▪ Increase/decrease a numerical value
Esc
Escape key:
▪ Cancel entry without saving it.
▪ When entering numbers: Go to the previous digit.
▪ Move up one menu level.
OK
OK key:
▪ Confirm entries.
▪ Confirm a menu selection.
▪ When entering numbers: Go to the next digit.
1. Switch on LevelControl Basic 2.
2. Press the "ESC" and "OK" keys simultaneously: P3.1.2.1 is displayed.
3. Press "OK": The display of the lifting unit starts to flash.
4. Refer to the lifting unit's name plate for the unit type (e.g. UZ10.450D), look up
the relevant setting in the table shown below (e.g. 39 for UZ10.450D) and make
the appropriate setting (e.g. 39) using the "Up" and "Down" keys of the control
unit.
5. To confirm, press "OK".
6. Press "ESC" to exit parameterisation.
Table4: Setting the unit type
Unit Setting Unit Setting Unit Setting
U1.100 E 1 U5.300 D 18 UZ5.450 D 35
U1.100 D 2 UZ1.150 E 19 UZ3.900 D 36
U2.100 E 3 UZ1.150 D 20 UZ4.900 D 37
U2.100 D 4 UZ2.150 E 21 UZ5.900 D 38
U3.100 D 5 UZ2.150 D 22 UZ10.450 D 39
U4.100 D 6 UZ3.150 D 23 UZ11.450 D 40
U5.100 D 7 UZ4.150 D 24 UZ12.450 D 41
US1.100 E 8 UZ5.150 D 25 UZ13.450 D 42
US1.100 D 9 UZS1.150 E 26 UZ14.450 D 43
US2.100 E 10 UZS1.150 D 27 UZ15.450 D 44
US2.100 D 11 UZS2.150 E 28 UZ10.900 D 45
U1.150 E 12 UZS2.150 D 29 UZ11.900 D 46
U1.150 D 13 UZ3.300 D 30 UZ12.900 D 47
U2.150 E 14 UZ4.300 D 31 UZ13.900 D 48
U2.150 D 15 UZ5.300 D 32 UZ14.900 D 49
U3.300 D 16 UZ3.450 D 33 UZ15.900 D 50
U4.300 D 17 UZ4.450 D 34
