5. INSTALLATION
• MONITOR CONNECTION
- DC12V/AC24V
- DC12V
10
When you install the camera, please glue the end of cable to
keep it stable in order to protect the camera from humidity problems.
CAMERA
BNC FEMALE
DC12V/AC24V
POWER SUPPLY
DC12V/AC24V
(TERMINAL BLOCK)
VIDEO IN
MONITOR
CAMERA
BNC FEMALE
DC12V
(DC JACK)
DC12V ADAPTER
VIDEO IN
MONITOR
