5. Safety Protection
When the PC video signal exceeds the frequency range of the
display, the display will disable the line and field synchroniz-
ing signals to protect the display. Under this circumstance,
you must set the output frequency of the PC to an acceptable
range for the display to work properly.
7.Simple Problems Disposal
6.Power Management System
Mode
Normal Operation
Standby
Power Consumption
so.5W
Remark: If there is a subtle difference between the User Guide
and the actual operation, the latter shall prevail.
Disposal Methods
Symptoms
I.Blanl< screen /Power indicator
does not worl<
2,BIurred too large or too
small images
3.Dark screen
4,Disploy overheating
5.Dark/light spots when
powered on
6.1moge distortion, flashing,
shal<ing
7,Noisy signal when powered off
Check whether the power supply is in good contact with the display and the power
socket; and check whether the display is turned off.
Go to the "Image Settings" category menu and select "Image Auto Adjust" to make
the monitor adjust automatically to correct.
(Only available for monitors with VGA)
Enter the "Brightness & Contrast" menu to regulate the contrast and the brightness
of the display.
Leave at least 5cm of ventilated space around the display,
Do not place articles on the display.
It is normal. Because of the temperature difference in the environment, the backlit tube
emits uneven light at the initialstage after the display turns on. However, the backlit
tube will emit normal light after 20 minutes, and the dark/light spots will be eliminated
at that time.
Check your computer configuration, choose the correctresolution, and reset your
refresh rate,
During the power-off of the display, there may be some noisy signals on the screen
caused by the normal discharge.
8. Product Technical Specifications
Panel Dimension
Best Operating
Resolution Ratio
Input Voltage
Contrast
Active Area
Pixel Pitch
Pitch size for wall mount
Maximum elevation
24
@ 144Hz
DC 12V / 3.0A
1000: 1 (TYP)
527.04mm x 296.46mm
0.274504) x 0.274501)
100mmx100mm
5000m
Working condition
Storage condition
Packing Dimension (WxHxD)and Weight
Display Dimension (WxHxD)(excludingbase)
Packing Dimension (WxHxD)
Net Weight of Display (includingbase)
Packing Weight
Temperature: OC —40 C
Humidity: 900/0
Atmosphere: 86kPa 1061<Pa
-20c 55 c
Temperature :
Humidity: 200/0 930/0(40C)
Atmosphere: 861<Pa 106kPo
539.9x319.4x44mm
620x475x115mm
2.8Kg
4.0Kg
The terms HDMI and HDMI High-Definition Multimedia Interface,and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Adminstrator,lnc. in the United
States and other countries.
