3.1

Power

Indicator

The

blue

indicator

represents

the

proper

functioning

of

the

display;

the

red

flash

indicator

represents

no

signal

state.

Under

the

energy

conservation

state,

the

display

will

normally

work

if

the

signal

is

provided

again.

The

display

is

still

powered

on

in

the

standby

state.

Thus,

unplug

the

power

cord

when

you

do

not

use the disploy

for

safety.

3.2

Key

Function

Introduction

Initial

Status:

Joystick

Upward

Shortcut

Menu

for

Signal

Source

Joystick

Downward

Shortcut

Menu

for

Volume

Joystick

Leftward

Shortcut

Menu

for

Gaming

Assistance

Joystick

Rightward

Preset

shortcut

keys

R

B

T

Enter

the

Function

Menu:

Joystick

Upward

Move

upward/Adjust

the

value

of

the

selected

item

Joystick

Downward

Move

downward/Adjust

the

value

of

the

selected

item

Joystick

Leftward

Return

the

previous

menu

Joystick

Rightward

Open/0K

Press

Joystick

Turn

off

the

display

by

pressing

and

holding

for

3

seconds

3.3

Safety

Protection

When

the

PC

video

signal

exceeds

the

frequency

range

of

the

display,

the

display

will

disable

the

line

and

field

synchronizing

signals

to

protect

the

display.

Under

this

circumstance,

you

must

set

the

output

frequency

of

the

PC

to

an

acceptable

range

for

the

display

to

work

properly.
