FINAL DRIVE 69T / 10T, chain 219H
FRAME Steel double cradle tube frame, powder-coated
WHEELBASE 37” (94 cm)
SEAT HEIGHT 20.5/23” (52 cm without seat, 59 cm with seat option)
HANDLEBAR HEIGHT 32.5” (83 cm)
FRONT BRAKE AND REAR BRAKES Hydraulic Disc Brake system Tektro Auriga
BRAKE DISCS 160 mm diameter
FORKS Suspension fork Spinner Grind
SHOCK ABSORBER Spring
TIRES 16” × 2.4” KENDA
WEIGHT 72 lbs (33 kg)
COLORS White
WIFI WiFi ready - adapter sold separately
CARRYING CAPACITY Maximum 220 lbs (100 kg)
WARNING!
The KUBERG TRIAL E is designed to operate at 36 volts only. Use of any battery voltage other than
24 volts will result in motor failure. KUBERG Inc. considers modications and/or changes to its
electrical components to be a material alteration of its products, thereby cancelling any warran-
ties and/ or guarantees in their entirety. Kuberg Inc. will not be responsible for any injuries, and/
or death and/or other damage(s) caused by such modications.
