Kubota B2301 Workshop Manual

TRANSMISSION
B2301, B2601, WSM
2-S6
TRANSMISSION CASE AND DIFFERENTIAL GEAR
9Y1211156TRS0002US0
Item Factory Specification Allowable Limit
Shift Fork to Shifter Groove Clearance 0.10 to 0.35 mm
0.004 to 0.014 in.
0.5 mm
0.020 in.
Differential case to Differential Side Gear
• Differential Case (Spiral Bevel Gear)
• Differential Side Gear Boss
Clearance
I.D.
O.D.
0.025 to 0.066 mm
0.0010 to 0.0026 in.
32.000 to 32.025 mm
1.2598 to 1.2608 in.
31.959 to 31.975 mm
1.2582 to 1.2589 in.
0.30 mm
0.0118 in.
–
–
Differential Pinion to Differential Pinion
Shaft
• Differential Pinion
• Differential Pinion Shaft
Clearance
I.D.
O.D.
0.048 to 0.084 mm
0.0019 to 0.0033 in.
16.032 to 16.050 mm
0.63119 to 0.63188 in.
15.966 to 15.984 mm
0.62859 to 0.62929 in.
0.30 mm
0.0118 in.
–
–
Differential Pinion to Differential Side Gear Backlash 0.1 to 0.3 mm
0.004 to 0.012 in.
0.4 mm
0.016 in.
Spiral Bevel Pinion Shaft Movements at
Shaft Directions
Approximately
0 mm
0 in.
–
Spiral Bevel Pinion to Spiral Bevel Gear Backlash 0.10 to 0.30 mm
0.0039 to 0.012 in.
–
KiSC issued 11, 2014 A

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
