CABIN
B2650HSDC, B3350HSDC, WSM
9-S6
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-11.)
9Y1210822CAS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 167 to 191 17 to 19.5 123 to 141
Rear wheel mounting bolt 196 to 225 20 to 23 145 to 166
Universal joint mounting bolt 24 to 28 2.5 to 2.8 18 to 20
Cabin mounting bolt and nut 124 to 150 12.7 to 15.2 91.5 to 110
High pressure pipe and low pressure pipe mounting
screw
7.90 to 11.8 0.806 to 1.20 5.83 to 8.70
Compressor mounting screws 24.5 to 29.4 2.50 to 2.99 18.1 to 21.6
Magnetic clutch mounting screw 15 to 21 1.5 to 2.1 11 to 15
Outer roof mounting bolt 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
A/C unit mounting screw (M6) 4.0 to 6.8 0.40 to 0.70 2.9 to 5.0
A/C unit mounting screw (M8) 9.81 to 11.6 1.00 to 1.19 7.24 to 8.60
Low pressure pipe (Cooler pipe (suction)) retaining nut 7.90 to 11.8 0.806 to 1.20 5.83 to 8.70
High pressure pipe (Cooler pipe (liquid)) retaining nut 11.8 to 14.7 1.21 to 1.49 8.71 to 10.8
Low pressure hose mounting screw (compressor side) 7.9 to 11 0.80 to 1.2 5.8 to 8.6
High pressure hose 1 mounting screw (compressor
side)
7.9 to 11 0.80 to 1.2 5.8 to 8.6
High pressure hose 1 mounting screw (condenser side) 7.9 to 11 0.80 to 1.2 5.8 to 8.6
High pressure hose 2 retaining nut (receiver side) 12 to 14 1.2 to 1.5 8.7 to 10
High pressure pipe 2 retaining nut 11.8 to 14.7 1.21 to 1.49 8.71 to 10.8
Low pressure pipe retaining nut 7.90 to 11.8 0.806 to 1.20 5.83 to 8.70
Wiper motor mounting nut 6.4 to 9.3 0.65 to 0.95 4.7 to 6.8
Wiper arm mounting nut 7.9 to 9.8 0.80 to 1.0 5.8 to 7.2
Wiper motor mounting screw 7.9 to 9.8 0.80 to 1.0 5.8 to 7.2
