97PERIODIC SERVICE
[CAB Type]
C Protected circuit
B3150 / B3150SU [ROPS Type]
FUSE
No.
CAPACITY
(A)
Protected circuit
(1) 30 Key Stop
(2) 10 Flasher / Hazard
(3) 5 Panel
(4) 10 Brake Stop Lamp
(5) 5 Glow Relay
(6) 10 Head Light
(7) 5 Panel / OPC
(8) 5 Dynamo / ACC Relay
(9) 10 Outlet (Right side)
(10) 10 Outlet (Rear)
(11) 5 Spare Fuse
(12) 10 Spare Fuse
(13) 30 Spare Fuse
(14)
Slow blow
fuse
Check circuit against wrong battery
connection
