UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
NOTE:
This machine is meant for cutting lawn only, not for cutting extensive maintained grass, not for cutting hedges or
brushwood, not for removing snow and not for pulling any implement or trailer.
Safety Alert Symbol
Read Operator's Manual
Hourmeter/Elapsed Operating Hours
Fuel-Level
Diesel Fuel
Coolant Temperature
Preheat
Brake
Parking Brake
Battery
Oil Pressure
Turn Signal
Engine-Stop
Engine-Run
Starter Control
Power Take-Off Clutch Control-Off Position
Power Take-Off Clutch Control-On Position
Differential Lock
Cutting Height
Mower-Lowered position
Mower-Raised position
Headlight-Low Beam
Headlight-High Beam
Beacon Light
Audible Warning Device
Hazard Warning Lights
Position Light/Parking Light
Fast
Slow
Master Lighting Switch
Speed set-Off
Speed set-On
Electrical Power-accessories
Grass Container-Lowered Position (HD)
Grass Container-Raised Position (HD)
Grass Container Tilted Forward Position (LD)
Grass Container Tilted Backward Position (LD)
Grass Container Tilted Forward Position (HD)
Grass Container Tilted Backward Position (HD)
Clean Lever-Open Position
Clean Lever-Closed Position
Engine Speed Control
