GENERAL
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
G-11
NOTE
• *KUBOTA UDT or SUPER UDT fluid: KUBOTA original transmission hydraulic fluid.
9Y1211167GEG0005US0
No. Place
Capacity
Lubricants, fuel and coolant
L5040-II L5240-II L5740-II
1 Fuel tank
54.0 L
14.3 U.S.gals
11.9 Imp.gals
• No. 2-D diesel fuel
• No. 1-D diesel fuel if
temperature is below –10 °C
(14 °F)
2
Cooling system
8.2 L
8.7 U.S.qts
7.2 Imp.qts
Fresh clean water with anti-freeze
Recovery tank
1.0 L
1.1 U.S.qts
0.88 Imp.qts
3
Engine
crankcase
(with filter)
9.4 L
9.9 U.S.qts
8.3 Imp.qts
Engine oil: API service
classification: CF or better
• Above 25 °C (77 °F)
SAE30, 10W-30 or 15W-40
• 0 to 25 °C (32 to 77 °F)
SAE20, 10W-30 or 15W-40
• Below 0 °C (32 °F)
SAE10W, 10W-30 or 15W-40
4
Transmission
case
46.0 L
12.2 U.S.gals
10.1 Imp.gals
41.0 L
10.8 U.S.gals
9.0 Imp.gals
KUBOTA UDT or SUPER UDT
fluid*
5
Front axle case
(4WD)
6.0 L
6.3 U.S.qts
5.3 Imp.qts
KUBOTA UDT or SUPER UDT
fluid* or SAE80, 90 gear oil
Greasing
Place No. of greasing point Capacity Type of grease
6
Front wheel
case support
2
Until grease
overflows
Multipurpose
type grease
NLGI-2 or
NLGI-1
(GC-LB)
Front axle
support
2
Top link 2
Top link bracket 2 (with draft control) (if equipped)
Lift rod 1
Lift cylinder 4
Battery terminal 2
Moderate
amount
Throttle cable Oiling Engine oil
KiSC issued 02, 2015 A
