7. Slide the drip tray (4) into the bracket
supplied for it in the base of the appliance
at the back (Fig. 7). Guide the little hole
at the end of the bowl frame onto the
protrusion to hold the tray in place.
(For easy cleaning, fill a little water into the
drip tray to cover the surface before using
the barbeque.)
8. Place the grill plate (3) on the base of
the appliance (5). First of all, insert the
appliance socket (15) into the opening
intended for it (12), then carefully lower the
grill plate onto the appliance base.
9. To attach the grill hood (1) to the base (5),
insert the two metal tabs into the
corresponding holes at the back of the
base (Fig. 9).
10. Push the temperature
regulator (13) as far
as it will go into the
appliance socket at the
side of the barbeque
(Fig. 10).
Your Electric Barbeque is
now fully assembled.
Getting Started (Cont.)
1
3
15
12
4
13
9
8
7
10
Back view
Front/side view
