32
INSTALLATION INSTRUCTIONS FOR CLASSIC MODEL COOKER HOODS
INSTALLATION VIDEOS OF ALL PRODUCTS AVAILABLE ON KÜGERR’S OFFICIAL WEBSITE
1st Sheet Metal Extension
Optional extension. If one sheet metal
chimney is enough, you do not need to
use this one.
2nd Sheet Metal Extension
If you are not going to use a second sheet metal
chimney for extension, use the connection
apparatus (A, B, and E) directly for the first
sheet metal chimney.
Detail D
