DPF-MRK-003 REV A 6/20/16
ROADTHUNDER SOUND BAR BY MTX, SATIN SILVER 2714
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
KURYAKYN.COM
INSTALLATION INSTRUCTIONS
INSTALLATION
SCENARIO 2 - INSTALL SOUND BAR, THEN MOUNTS CLAMPS TO HANDLEBAR.
• Choose the correct size strap clamp for the handlebars.
Note: Placing the transparent film between the strap clamp and handlebar will reduce the possibility of scratching the handlebars during installation.
• Slide the sound bar into the brackets from the left side, so the brackets can clear the buttons without damaging them.
• Ensure that the spacing between the brackets is between 3” and 6.75”.
• Assemble mid-section to bottom bracket using included 5mm Allen Screw and 10mm Hex Nut.
• Rotate the sound bar so the speakers are directed at the rider’s head.
• Tighten the 5mm Allen Screws to lock the sound bar in place.
• Tighten the 2mm Set Screws.
• Connect wires to power, ground, and ignition.
ORIENTATION EXAMPLES
-CONTINUED-
To Next Page
