Kurz 454FTB - Figure C-4. Zero Flow Calibration Chamber - Exploded View

KurzHardwareReferenceGuideC–6
ZeroFlowCalibration
AssembleandgluethepartstogetherasshowninFigure C‐4.

Figure C‐4. ZeroFlowcalibrationchamber—explodedview
11½”PVCplug
13”FNPTABScoupler
13”MNPTABSendcap
ABSorPVCcement
Table C‐1. ZeroFlowChamberPartsList(continued)
Quantity Description Image
