Kurz B Series Startup Guide

Kurz Instruments, Inc. 831-646-5911
2411 Garden Road www.kurzinstruments.com
Monterey, CA 93940
360208-F 454FTB, 504FTB, 534FTB 20
If SCROLLED format is selected for the Run Mode Display, the meter will prompt for
the combinations of process variables to be scrolled
SCROLLED VARS
>SCROLL ALL ^v
Use the ^ and v keys to scroll through the following combinations of process variables
and press E to accept the selection. The SCROLLED VARS list includes the following:
SCROLL ALL, FLOW ONLY, FLOW+TOT, FLOW+VEL, TAG+FLOW,
TAG+FLOW+VEL, FLOW+TOT+VEL, FLOW+TEMP, FLOW+TEMP+VEL
For the Run Mode scrolled format, each screen will display the value of only one process
variable; the description will be on line 1 and the value with units will be on line 2.
Flow
FLOW RATE
0.0000 SCFM
Temp
TEMPERATURE
82.52 DEGF
Velocity
VELOCITY
0.0000 SFPM
Totalized
Flow
TOTAL FLOW
183545.0 SCF
Tag Name
TAG NAME
NAT. GAS24
For scrolled format, the user also defines the scroll interval. The scroll interval defines
the time interval between screen updates to scroll to the next screen/displayed variable.
This value must be at least 2 seconds, but can be up to 8 seconds. Use the numeric keys
to enter the scroll interval in seconds and press E to accept the entry.
