Kurz B Series Startup Guide

Kurz Instruments, Inc. 831-646-5911
2411 Garden Road www.kurzinstruments.com
Monterey, CA 93940
360208-F 454FTB, 504FTB, 534FTB 21
SCROLL INTERVAL
>2 SEC
After the configuration data on the Quick Setup Menu has been entered, press H to exit
from the Quick Setup Menu and return to Run Mode. The user can also review the new
values before exiting by pressing P, repeatedly, to scroll through all the Quick Setup
parameters. After reviewing and verifying the new values, press H to exit and return to
Run Mode. On exit from the Quick Setup Menu (of Program Mode), the meter will save
the data to the EEPROM and will display the following screen to indicate the data is
being saved.
SAVING CONFIG
DATA TO EEPROM
Data saved to EEPROM is persistent between power cycles of the flow meter.
Meter Programming with the USB Port
The Quick Setup can also be performed using a PC/laptop running a terminal emulator
program, like TeraTerm. The Kurz USB driver must be installed on the PC for this to
work; the USB software is on the same disk as the full product manual.
Note, Tera Term can be installed from the CD manual or downloaded for free at
http://ttssh2.sourceforge.jp/ . As of this printing it is at version 4.65 and works on all
versions of Windows: 95 to 7. The program can be installed for the English, Japanese or
German language.
Plug the USB cable between the flow meter and the PC. If the driver is installed and
working properly, the USB connection will appear as one of the COM ports on the PC.
USB
Use the Tera
Term Program
KURZ USB
driver software

Kurz B Series Specifications

General

Accuracy	±0.1 m/s or ±1% of reading
Probe Material	Stainless Steel
Output	4-20 mA
Power	12-30 VDC
Operating Humidity	0 to 95% RH (non-condensing)
Power Supply	12-30 VDC
Battery Life	N/A (loop powered)
