System Exclusive Protocol
K2500 System Exclusive Implementation
11-7
Quick Access Bank 111 6Fh 00h 6Fh
Intonation Table 103 67h 00h 67h
Master Parameters
The Master parameters can be accessed as type 100 (00h 64h), ID number 16. Master parameters
cannot be accessed with any of the Bank messages.
Button Press Equivalence Table
Button
Code (hex) Button Code(hex)
Alphanumeric pad Soft-Buttons ‘A-F’
zero 00 A ‘(leftmost) 22
one 01 B 23
two 02 C 24
three 03 D 25
four 04 E 26
five 05 F (rightmost) 27
six 06 AB 28
seven 07 CD (two center) 29
eight 08 EF 2A
nine 09 YES 26
+/- 0A NO 27
Alphanumeric pad Edit/Exit
CANCEL 0B EDIT 20
CLEAR 0C EXIT 21
ENTER 0D
Navigation Mode Selection
Plus (+) 16 PROGRAM 40
Minus (-) 17 SETUP 41
Plus and Minus 1E QUICK ACCESS 42
CHAN/BANK Inc 14 EFFECTS 47
CHAN/BANK Dec 15 MIDI 44
CHAN/BANK Inc/Dec 1C MASTER 43
Cursor Left 12 SONG 46
Cursor Right 13 DISK 45
Cursor Left/Right 1A
Cursor Up 10
Cursor Down 11
