DSP Functions
The DSP Functions
-70
-60
-50
-40
-30
-20
-10
0
10 100 1000 10000 100000
Frequency in Hertz
Amplitude in dB
Center frequency = C 7;
width = 2 octaves;
separation at -2, 0, +2 octaves
-2
0
+2
Twin Peaks
Separation
Bandpass Filter:
-70
-60
-50
-40
-30
-20
-10
0
10 100 1000 10000 100000
Frequency in Hertz
Amplitude in dB
Center frequency = C 7;
separation = 1 octave;
width at .5, 1, 2 octaves
2
.5
Twin Peaks
Width
Bandpass Filter:
