DSP Functions
The DSP Functions
16-41
the other parameters to determine the effect on the pitch, as indicated by the ÒxÓ after the
parametersÕ values. More parameter descriptions follow below.
EditProg:F1|PCH(LF|SIN)||||<>Layer:1/1||
Coarse:100.0Hz||||||Src1||:OFF||||||||||
Fine||:4.00x||||||||Depth|:1.000x|||||||
||||||||||||||||||||Src2||:OFF||||||||||
KeyTrk:|2.00x/oct|||DptCtl:OFF||||||||||
VelTrk:|1.000x||||||MinDpt:1.000x|||||||
Pad|||:0dB||||||||||MaxDpt:1.000x|||||||
<more||F1|PCH|F2|||||F3|||||F4|AMP|more>
Coarse Adjust (Coarse)
There are only Þve values to choose from. TheyÕre expressed in terms of their frequencies in
Hertz. Each value has a frequency ten times higher or lower than adjacent values.
Fine Adjust (Fine)
Set this parameterÕs value to 1.00 x if you donÕt want it to affect the Coarse Adjust setting.
Doubling this value (2.00 x, 4.00 x, etc.) will raise the pitch in octaves. By using Fine Adjust in
tandem with Coarse Adjust, you can achieve frequencies from .1 Hz (well below the audible
range) to 20 KHz.
Key Tracking (KeyTrk)
A value of 1.00 x per octave will keep the waveformÕs pitch uniform across the entire keyboard.
A value of 2.00 x per octave will give you the normal twelve-tone octave. Other values will give
you nonstandard tunings.
Added Waveforms
Parameter Range of Values
Coarse Adjust 0.1, 1.0, 10.0, 100.0, 1000.0 Hertz
Fine Adjust 1.00 to 20.00 x
Key Tracking 0.1 to 10.0 x per octave
Velocity Tracking 0.010 to 32.000 x
Pad 0, 6, 12, 18 dB
Source 1 Control Source list
Source 1 Depth 0.010 to 32.000 x
Source 2 Control Source list
Source 2 Depth Control Control Source list
Minimum Depth, Source 2 0.010 to 32.000 x
Maximum Depth, Source 2 0.010 to 32.000 x
SINE+
SAW+
NOISE+
