DSP Functions
The DSP Functions
SINE, Sawtooth (SAW), SQUARE
ThereÕs only one parameter on this control-input page that may still be unfamiliar to you:
Fine Hz. This is discussed on page 6-27. It can tune the pitch of the waveform in terms of its
actual frequency in Hertz, as opposed to the usual method of tuning by key names. The
advantage to using the Fine Hz parameter is that you can maintain constant beat frequencies
across much of the keyboard when you have a program with slightly detuned multiple layers
(or multiple waveforms in one layer).
EditProg:F1|PCH(SINE)||||||<>Layer:1/1||
Coarse:0ST||||||||||Src1||:OFF||||||||||
Fine||:0ct||||||||||Depth|:0ct||||||||||
FineHz:|0.00Hz||||||Src2||:OFF||||||||||
KeyTrk:0ct/key||||||DptCtl:OFF||||||||||
VelTrk:0ct||||||||||MinDpt:0ct||||||||||
Pad|||:0dB||||||||||MaxDpt:0ct||||||||||
<more||F1|PCH|F2|||||F3|||||F4|AMP|more>
If you want the waveform to play with standard twelve-tone octaves, set the KeyTrk parameter
to 100 cents per key. Different values for KeyTrk will result in nonstandard tunings.
Low Frequency Waveforms: Sine (LF SIN), Sawtooth (LF SAW), Square (LF SQR)
These can be used like the waveforms above, since their frequency ranges are similar, but theyÕre
intended to be used not for their timbres, but for the shape of their waveforms. By using low
frequency values for these waveforms, youÕre basically getting extra LFOs with very precise
control parameters. TheyÕre intended to be used as inputs to drive the DSP functions in the
subsequent algorithm blocks. TheyÕre especially useful with the nonlinear DSP functions, such
as xAMP.
The parameters on this page affect the pitch of the low frequency waveform in a slightly
different manner. TheyÕre all tied to the value of the Coarse Adjust parameter, so when youÕre
working with this page, youÕll want to set the Coarse Adjust Þrst, then set the values of the other
parameters to modify the initial setting. The Coarse Adjust value is multiplied by the values of
Parameter Range of Values
Coarse Adjust –120 to 60 semitones
Fine Adjust ± 100 cents
Fine Adjust in Hertz ± 6.00 Hertz
Key Tracking ± 2400 cents per key (2 octaves)
Velocity Tracking ± 7200 cents (6 octaves)
Pad 0, 6, 12, 18 dB
Source 1 Control Source list
Source 1 Depth ± 7200 cents
Source 2 Control Source list
Source 2 Depth Control Control Source list
Minimum Depth, Source 2 ± 7200 cents
Maximum Depth, Source 2 ± 7200 cents
