SysEx Control of KDFX
Device Codes
B-3
Device Codes
These codes identify the studio component that you want to control via SysEx. Use one of these
values for the device selection byte in the body of your SysEx message.
Parameter Codes
These codes identify the speciÞc parameters for each studio component (device). Use one of
these values for the parameter selection byte in the body of your SysEx message.
Device Code
(Hexadecimal)
Device Code
(Decimal)
Studio Component
00 0 Send1 for Input A (or for A Left if Input A receives a mono signal)
01 1 Send1 for Input A Right (if Input A receives a mono signal)
02 2 Send1 for Input B (or for B Left if Input B receives a mono signal)
03 3 Send1 for Input B Right (if Input B receives a mono signal)
04 4 Send1 for Input C (or for C Left if Input C receives a mono signal)
05 5 Send1 for Input C Right (if Input C receives a mono signal)
06 6 Send1 for Input D (or for D Left if Input D receives a mono signal)
07 7 Send1 for Input D Right (if Input D receives a mono signal)
08–0F 8–15 Send2 for Inputs A–D (if input is stereo, use 08, 0A, 0C, and 0E)
10–17 16–23 1st EQ block for Inputs A–D
18–1F 24–31 2nd EQ block for Inputs A–D
20, 22, 24, 26 32, 34, 36, 38 Aux send for FXBuses 1–4
21, 23, 25, 27 33, 35, 37, 39 Mix send for FXBuses 1–4
28 40 Mix send for Aux bus
29 41 Final mix
2A 42 FX Preset for Aux bus
2B–2E 43–46 FX Preset for FXBuses 1–4
Device Code
(Hexadecimal)
Parameter Code
(Hexadecimal)
Parameter Code
(Decimal)
Parameter
00–0F
00 0 Level
01 1 Pan or Balance
02 2 Width (for stereo inputs only)
10–1F
00 0 Gain (or Frequency if EQ block is hipass or
Lopass)
01 1 Frequency
20–29
00 0 Level
01 1 Balance
2A–2E
00 0 Wet/Dry (or In/Out)
01–2B 1–43 Variable, depending on FX Preset
