System Exclusive Protocol
K2600 System Exclusive Implementation
7-7
Object Types
These are the object types and the values that represent them in type Þelds:
Master Parameters
The Master parameters can be accessed as type 100 (00h 64h), ID number 16. Master parameters
cannot be accessed with any of the Bank messages.
Button Press Equivalence Tables
Type ID (decimal) ID (hex) ID (hex, type field)
Program 132 84h 01h 04h
Keymap 133 85h 01h 05h
Studio 113 71h 00h 71h
Song 112 70h 00h 70h
Setup 135 87h 01h 07h
Soundblock 134 86h 01h 06h
Velocity Map 104 68h 00h 68h
Pressure Map 105 69h 00h 69h
Quick Access Bank 111 6Fh 00h 6Fh
Intonation Table 103 67h 00h 67h
Alphanumeric pad Soft-Buttons A-F
Button Code (hex) Button Code(hex)
zero 00 A (leftmost) 22
one 01 B 23
two 02 C 24
three 03 D 25
four 04 E 26
five 05 F (rightmost) 27
six 06 AB 28
seven 07 CD (two center) 29
eight 08 EF 2A
nine 09 YES 26
+/- 0A NO 27
