this amplifier is 4 ohms.
This 1/4” jack is used to connect the amplifier to another line level piece of equipment, such as a mixer.
The output from this jack is after the preamp, so all of the controls on the amplifier will affect the sound
from this jack.
processor should be connected to this jack. Note: This jack can also be used as a power amp in jack.
jack.
Mo de l DE 20 0 HD Ba s s Am p li fie r
20 0W 4 o hm @ 5% TH D
Ou tp u t P owe r
12 0W 8 o hm @ 5% TH D
Fr equ en c y Re s po n se
20 Hz - 19 k Hz Ac tua l res pon se is ta il o r ed to s p ea k er c a bi net fo r
ac c ur ate a c ou sti cal r esp o ns e .
To ta l H arm on i c D is tor ti o n
Le s s tha n 0 .4 % Me as u re d a t 1 V RM S (0 d Bv) a t d ir ect ou tp u t, ef fec t s
sen d, or l ine o utp u t
-6 0dB Re s id ual N oi s e, al l l e ve l c o nt ro l s 0% (m i ni mum )
Hu m & No is e
-5 0dB No m in al Syste m Noi se, all l e ve l con t ro ls at 5 0 %
Al l m eas ur eme nts m a de at 1k H z
40 d B CD / Tape In put t o P o we r A mp Ou t
60 d B Ba s s Inp ut to Po we r A m p Ou t
-5 dB CD / Tape In put t o L i ne Out pu t
40 d B Ba s s Inp ut to L ine Ou tput
-5 dB CD / Tape In put t o D i re c t Out pu t
Sy st em Gai n
40 d B Ba s s Inp ut to Di re ct Ou t put
Eq ual iza ti o n 63 to 5 k Hz, 6 Ba nd Gr ap h ic, a l l ±1 2dB
Po we r Requ ir e me n ts US A/ C an ada 12 0 VA C/6 0H z, 30 0W no mi n al
Eu rop e 23 0 VA C/5 0H z, 30 0W no mi n al
UK 23 0 VA C/5 0H z, 30 0W no mi n al
Au s tr al i a 24 0 VA C/5 0H z, 30 0W no mi n al
Jap an 10 0VAC/ 50- 60 H z, 30 0W n om i na l
Di m en sio ns mm
in c he s
89 (H ei ght ) x 4 8 2 (W i dt h) x 2 45 ( De pt h)
3 1 /2 ( H ei g ht ) x 1 9 (W i dth) x 9 3/ 5 (Dep th )
W ei g ht kg/ lb s 7 kg / 15 l b s
