Output Power 1% 50W 8 Ohm load
CH 1 and 2 Mic XLR Balanced, Line level 1/4" Un-balanced
onom dexim ,oeretS leveL enil/enohpdaeH "8/13HC
-65dB Residual Noise, all level controls 0% (minimum)
-48dB Nominal System Noise, all level controls at 50%
+70dB Mic to Speaker Output (CH 1 & 2)
+56dB Line to Speaker Output (CH 1 & 2)
+42dB AUX IN to Speaker Output
Channel EQ (high, low)
Subwoofer Out Line Out 20Hz-150Hz.
Phantom Power
+15V Mic inputs (Ch 1 & 2)
USA/Canada 120VAC/60Hz, 80W nominal
Europe 230VAC/50Hz, 80W nominal
lanimon W08 ,zH05/CAV032KU
Australia 240VAC/50Hz, 80W nominal
Japan 100VAC/50-60Hz, 80W nominal
Speakers Two 4½" 50W 4 Ohm each
revird ozeip"2/1 3 nroH
Power Capacity
50W RMS
60HZ-20kHz
Full range (subwoofer jack not used)
150HZ-20kHz
Crossover Active (1/4" mono plug in subwoofer jack)
Nominal Impedance 8 Ohms Not designed for external speakers
mm/kg 190 (width), 460 (height), 165 (depth), 6.7 kg
Inches/Pounds 7½ (width), 18 (height), 6½ (depth), 14.7 lb
Dimensions & Weight
4kHz and above , 800Hz and below.
Power Requirements
SYNC (IN and OUT)
Both jacks accept a balanced input and sends a pre-master volume output mix of
channels. Recommended use: Linking two PA50's together.
System Gain
(Measurements made at
1kHz)
Frequency Response 20HZ-20kHz
Actual response is tailored to speaker cabinet for
accurate acoustical response.
Accepted Inputs
Hum & Noise
Frequency Response
onom dexim ,oeretS leveL enil/enohpdaeH "8/13HC
lanimon W08 ,zH05/CAV032
revird ozeip"2/1 3 r
PA50 Powered PA Specifications
Power Requirements
System Gain
(Measurements made at
1kHz)
Hum & Noise
Frequency Response
