Section 3.0 - Quick Reference Guide
Work Safely. Always wear safety glasses near the machine.
F9
Edit Job
Allows full editing, adding
and deleting lines
F9
Job Must be Loaded
Scroll to desired function using the + & - keys
ENT
ENT
ENT
Type line positions or teach
positions by jogging the machine
ENT
ENT
OR
Y
Does NOT
Save Work
N
ENT
ENT
Will return to selection screen
ENT
Once Deleted, will take you
back to the menu
ENT
Use the scroll down to nd
the line you want to delete,
then hit ENT
ENT
Follow the
Prompts
Accept default le name or
type over to Save As
ENT
ENT
Job LOADED
Ready to Run
SPACE BAR
SPACE BAR to:
Run & Pause
To Next Page
