KYMCO PEOPLE 250 Service Manual

14.STEERING HANDLEBAR/FRONT WHEEL/FRONT
BRAKE/FRONT SHOCK ABSORBER/FRONT FORK
14-16
PEOPL E 25 0
INSTALLATION
Apply grease to the top and bottom ball races
and install 26 steel balls on the top ball race
and 19 steel balls on the bottom ball race.
Then, install the front fork.
Apply grease to the top cone race and install
it.
Tighten the top cone race and then turn the
steering stem right and left several times to
make steel balls contact each other closely.
Install the steering stem lock nut and tighten
it while holding the top cone race.
Torque: 80_ 120N-m
Install the front wheel. (
!
14-7)
Install the front brake caliper. (
!
14-12)
Install the front fender cover A and B. (
!
2-6)
Install the throttle grip and the right and left
handlebar switches.(
!
14-5)
Install the right and left brake master
cylinders. (
!
14-5)
Lock Nut Wrench
Lock Nut Wrench
Bottom Ball Race
Check that the steering stem rotates
freely without vertical play.
＊

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
