KYMCO SPADE 150i User Manual

6-6
6
● Is braking effective?
● Drive slowly to verify the effect of front and rear
brakes.

Check and adjust Brake Light:
● Turn Main Switch to ON position.
● Respectively pull the Front and Rear Brake Levers;
verify if Brake Light goes on.
● Check Brake Light for stain or fracture.

KYMCO SPADE 150i Specifications

General

Bore x Stroke	57.4 mm x 57.8 mm
Compression Ratio	9.3:1
Fuel System	Electronic Fuel Injection (EFI)
Transmission	5-speed manual
Front Suspension	Telescopic fork
Brakes (Front)	Disc
Brakes (Rear)	Drum
Ground Clearance	150 mm
Engine Type	4-stroke
Max Power	8, 500 rpm
Max Torque	11.5 Nm
Starting System	Electric
Fuel Tank Capacity	5.5 L
