L-TEC PLASMAWELD 402 - Manual Metal Arc Welding Setup

11
E. Manual Metal Arc Welding
1. Remove TIG- or plasma-torch control cable plug (Water pump is now out of operation).
2. Connect electrode holder
3. Set switch
k to symbol
4. Set switch
f to mid position
5. Keep button
E depressed and adjust welding current. Amperage is preset at potentiometer a and can
be read from ammeter D.
Installation
