A 5 pol socket for control plug
B Central connector for torch
C Socket for pilot circuit
G 5 pol socket for remote controls
F Foot remote control FC 4 – Manual remote control – Puls unit
H Socket for work return lead and electrode holder lead
Spare parts list for power source PLW 202 / 402
