the impeller:
1. Remove tower cover.
2. Push the shaft brake backwards and hold.
3. With the brake applied, use your thumb and
forefinger to remove the impeller clockwise.
4. Clean impeller with a soft dry cloth.
5. With the impeller removed, clean around the
bayonet ring and collection area with a brush and
wipe away loose grounds.
6. With the brake applied, reinstall the impeller by
turning counterclockwise.
1 5
3
2
6
preventative maintenance
Preventative maintenance should be performed on a
quarterly basis and should be carried out by a service
technician. This maintenance should include checking
and adjusting the coffee dose, deep cleaning the grind
chambers, and replacing the burrs if applicable. Burr
replacement should occur every 2000 lbs or if burrs
are damaged.
