Appendix A: Freeze Dryer Components
Product Service 816-333-8811 or 1-800-522-7658
46
Models 76700xx and 74200xx
Item Part No. Description
1 7395800 Lid Gasket
2 7395801 Lid
3 7435800 Back Panel Assembly, 115V
7435900 Back Panel Assembly, 230V
4 7953800 Motor Fan, 115V
7953801 Motor Fan, 230V
5 7591805 Compressor, 115V, 60 Hz Lo Stage
7591806 Compressor, 230V, 50 Hz Lo Stage
7591807 Compressor, 230V, 60 Hz Lo Stage
7591805 Compressor, 115V, 60 Hz Hi Stage
7591806 Compressor, 230V, 50 Hz Hi Stage
7591807 Compressor, 230V, 60 Hz Hi Stage
7591805 Compressor 115V/60 Hz Single Stage
7591806 Compressor 230V, 50 Hz Single Stage
7591807 Compressor 230V/60 Hz Single Stage
6 1302300 Switch
7 7426000 Control Panel Label
8 7445590 Printed Circuit Board
9 7728000 Drain Plug
10 1643600 O-Ring
11 7645906 Drain Hose
12 7373450 Vacuum Hose (Not Shown)
13
1336400 Power Cord 115V 60Hz (Not Shown)
1336500 Power Cord 230V 50Hz EU (Not Shown)
1342100 Power Cord 230V 60 Hz (Not Shown)
1332601 Power Cord 230V 50Hz UK (Not Shown)
1332701 Power Cord 230V 50Hz China (Not Shown)
14 7445400 Vacuum Sensor (Not Shown)
15 7515300 Temperature Sensor, Collector (Not Shown)
16 7427502 Wire Harness, 115V (Not Shown)
7427503 Wire Harness, 230V (Not Shown)
17 7432700 Vacuum Control/Bleed Valve
18 7429700 Moisture Sensor
19 7418400 Wire Harness, Control, 115V and 230V (Not Shown)
