Labelmate LD-100-RS User Manual

Labelmate.com
LABELMATE label dispensers are a quick and easy way to dispense individual labels. They use a
peel and present design: as the material passes through the dispenser, the label is peeled away from
the backing material and presented at the front of the unit where it waits to be picked up by the op-
erator.
FEATURES
• All Label Dispensers (except AWB) come with 38mm core holders accepting all cores between 40 and 76mm
• AWB Option comes standard for Cores in diameter 76mm. Available on request for 38,40,44,50,70 and 100mm cores
• Maximum Label Roll Weight: 6 KG
• Minimum Speed: 11 CM/SEC
• External roll diameter LD-100 & LD-200 : 220 mm standard
• External roll diameter LD-100 & LD-200 : 265 mm with AWB option
• External roll diameter LD-100 & LD-200 : 300 mm with LD-DE option
• External roll diameter LD-300 : 300 mm
DIMENSIONS
• LD-100 models W x D x H: 210 x 200 x 270 mm
• LD-200 models W x D x H: 270 x 200 x 270 mm
• LD-300 models W x D x H: 300 x 250 x 295 mm
• Shipping Weight: 6 to 8 KG depending on model & selected options
MANUAL VALID FOR FOLLOWING PRODUCTS:
P/N MODEL
LABEL
WIDTH
(MM)
MIN LABEL
LENGTH
(MM)
STAINLESS
STEEL
REGULAR LABELS
LMD001 LD-100-RS up to 115 6
LMD003 LD-100-RS-SS up to 115 6 x
LMD002 LD-200-RS up to 165 6
LMD004 LD-200-RS-SS up to 165 6 x
LMD014 LD-300-RS-SS up to 218 50 x
ALL LABELS, INCL TRANSPARENT & BLACK
LMD005 LD-100-U up to 115 20
LMD007 LD-100-U-SS up to 115 20 x
LMD006 LD-200-U up to 165 20
LMD008 LD-200-U-SS up to 165 20 x
LMD016 LD-300-U-SS up to 218 50 x
GENERAL
• Power Supply: 220-240VAC- 50Hz DC, Output 15V-4,33A
• Limited Warranty of 3 Years, 1 Year on the Power Supply
IMPORTANT NOTICE
• Keep Label Sensor Eye clean. Wipe with a soft cloth occasionally. Be careful not to damage the sensor. Do not use any
chemical on the Sensor.
• Keep Tape Stripper Bar and Web Guide Bars clean. Use isopropyl alcohol or “Goo-Gone”™ to clean adhesive residue
from parts. Adhesive build-up can cause malfunction and damage to your unit.
• Remove all parts from the shipping
container and verify contents.
PACKAGE CONTENTS:
• User Manual (this document)
• Label Dispenser Unit
• Power Supply Module
• Retain the Shipping Container and
Packaging for Storage and Transport.
