H50/150 Smart – User Manual
6
REAR VIEW
The rear panel consists of the following parts:
SPECIFICATION
The H50 series recirculating water chiller is designed to provide continuous supply of cooling
fluid at a constant temperature and flow rate. The unit consists of an air-cooled refrigeration
system, a plate heat exchanger, a recirculating pump, a reservoir and a microprocessor
temperature controller.
Technical specification:
Model
H50-500
/115V
H50-500
/DF
Temp. control range
-5℃～35℃
Temp. control mode
PID
Cooling mode
Compressor cooling
Temp. stability
±0.3 ℃
Refrigerant
R134A
Cooling capacity/W
500W@25℃
Pump capacity
3L/min@10psi
Reservoir volume
1,8L
Pressure
1Bar
Weight
28Kg
Dimension(LxWxHmm)
480×250×500mm
NOTE: the value of temperature stability is tested in standard operating mode.
Liquid Supply Connection
Liquid Return Connection
Electrical Socket
Liquid Drain
