PARTS LIST
1.- Ventilation grille
2.- Heating surface
3.- "POWER" Function Indicator
4.- "TEMP" Function Indicator
5.- TIMER button
6.- SELECT button
7.- +/- Buttons
8.- Power level/temperature scale
9.- ON/OFF button
10.- LOCK button
11.- "WARM" Function Indicator
12.- Display
1.- Connect the plug to a suitable mains electricity outlet. An audible signal will sound
automatically and the display (12) will light up for a moment.
2.- Place a cooking utensil suitable for using on a ceramic hob on the heating surface (2).
3.- Press the ON/OFF button (9) to switch on the hob and an LED will light up on the button
(Picture 1).
6 7 8 7 9
5 10
11
12
2
4
3
1
OPERATION
