LAE AT2-5 Series User Manual

LTR-5
77x35x77mm
Single output on/oFF or piD thermoStat
or humiDiStat
Runs on mains power supply PID with autotuning or ON/OFF control Output on
relay (16A) or SSR piloting Input for PTC, NTC10K or 0÷1V 0.1 / 1°C or 1°F
resolution Refrigerating (dehumidifying) or heating (humidifying) control mode selection
Stand-by button on the front Load start limitation and safety function in the event
of breakage of the sensor Quick setup through ZOT-LTR device Connection to LAE
supervisory systems TAB.
Temperature: Control of small cold stores, refrigerated cabinets and tables, heating systems, heated cupboards, bains-
marie, ovens, laboratory equipment.
Humidity: Control of greenhouses, seasoning cells, cold rooms, air-conditioned rooms.
applicationS:
How to order examples:
LTR-5CSRE-A (NTC10K input, 1 relay, screw terminals, 230Vac supply, TTL port)
LTR-5ASRU (0÷1V input, 1 relay, screw terminals, 115Vac supply, no serial port)
On request, the LTR-5 is also available with gasket for a better protection between bezel and panel.
(a) -50÷140°C; (b) -40÷110°C; (c) remaining range.
LTR-5 Series
POS.
S= screw terminals; Q= male+female terminals
FUNCTION
Output type
Connectors
Supply
Serial comm.
1 2 3 4 5
1
2
3
4
5
LTR-5 T SRE
Input
DESCRIPTION
T = PTC; C= NTC10K; A= 0÷1V
R = relay; F = SSR drive
D =12Vac/dc; E =230Vac; U =115Vac, 2W
- = no serial port; -A = TTL; -B = RS485
LTR-5T.. LTR-5C..
Functions
Range
Input type
Accuracy
PTC NTC10K
-50÷150 ° C
-60÷300 ° F
±0.3°C
(a)
; ±1.0°C
(c)
0÷99.9% r.H.
Resolution
0.1/1°C; °F
0.1/1 %
r.H.
Front protection
IP55
LTR-5A..
0÷1V
-40÷125 ° C
-40÷260 ° F
±0.3°C
(b)
; ±1°C
(c)
±0.7% r.H.
-B
Panel cut-out
71x29 mm
Ambient temp.
-10÷50°C
LTR-5 Series
POS.
S= screw terminals; Q= male+female terminals
FUNCTION
Output type
Connectors
Supply
Serial comm.
1 2 3 4 5
1
2
3
4
5
LTR-5 T SRE
Input
DESCRIPTION
T = PTC; C= NTC10K; A= 0÷1V
R = relay; F = SSR drive
D =12Vac/dc; E =230Vac; U =115Vac, 2W
- = no serial port; -A = TTL; -B = RS485
LTR-5T.. LTR-5C..
Functions
Range
Input type
Accuracy
PTC NTC10K
-50÷150
° C
-60÷300
° F
±0.3°C
(a)
; ±1.0°C
(c)
0÷99.9% r.H.
Resolution
0.1/1°C; °F
0.1/1 %
r.H.
Front protection
IP55
LTR-5A..
0÷1V
-40÷125
° C
-40÷260
° F
±0.3°C
(b)
; ±1°C
(c)
±0.7% r.H.
-B
Panel cut-out
71x29 mm
Ambient temp.
-10÷50°C
