Specification
Table dimensions 1000mm X 550mm [39 3\8”X 21
5/8”]
Spindle opening diameter 190mm [7,48”]
Spindle diameter 31,75mm [1 ¼”]
Vertical spindle movement 175mm [6,89”]
Spindle tilt angle 90 to –45 degrees
Spindle speeds 1400, 3500, 6000, & 8000 rpm
Tool diameter max [profile
cutter]
180mm [7,08”]
Tool diameter max [pin cutting] 250mm [9,84”]
Motor power 4,8kW [5,5hp] With breaking [-
10 sec]
Max usage 10 times per hour
Dust collection diameter
[cabinet]
101,6mm [4”]
Dust collection diameter [hood] 120mm [4 ¾”]
Machine weight 390kg [858lb] approx
Standard equipment supplied
Shaper hood Yes
Adjustable fence rails [Fingers] Yes
Miter fence 1016mm extendable to 1727mm
[40” extendable to 68”]
Job clamp Yes
Sliding table side clip on table 317mm X 498mm [12 ½” X 19
5/8”]
Tool kit Yes
Push pull handle Yes
Options
Mobility kit Yes
Sliding table side clip on table 317mm X 498mm [12 ½” X 19
5/8”]
Flip stops Yes
Cutters Various
Tennioning table Yes
5
