Laing Thermotech ACT-4 User Manual

24 pages

To Next Page

Installation, Operation

and Maintenance Manual

Laing Thermotech ACT-4 wireless

Potable Hot Water Recirculation Kit

Questions and Answers:

J
Jimmy JohnsonAug 13, 2025
What to do if my Laing Thermotech ACT-4 pump does not turn on?
- M
  Michael WatersAug 13, 2025
  If your Laing Thermotech Plumbing Product pump isn't turning on, there might be a few reasons: * The timer slide switch could be in the “OFF” position, or the timer clock isn't programmed correctly. In that case, set the slide switch to the “ON” position or program the timer clock. * The water at the valve might already be at the set temperature. The pump will turn on when the water at the valve cools. Verify the temperature setting on the pump. * The outlet may not have power. Check that there is power at the outlet and that the outlet isn't controlled by a wall switch. * The GFCI might be tripped. Verify the “TEST” and “RESET” of the GFCI outlet.
B
Bruce SantanaAug 17, 2025
How to fix a noisy Laing Thermotech ACT-4 Plumbing Product pump?
- E
  Emily HarrisonAug 17, 2025
  If your Laing Thermotech Plumbing Product pump is making noise, consider these possibilities: * There may be air in the system. Turn off the ecocirc pump and turn on the hot and cold faucets/taps until all air is purged from the system. * There could be foreign matter in the rotor cavity. Unplug the pump, shut off the water supply, open faucets/taps to drain water, and loosen the screw ring to check for foreign matter. * The rotor might not be seated properly. Ensure the rotor is properly set on the motor bearing by pushing down on the rotor. * Water hammer could be resulting from the closure of the built-in check valve. Install water hammer arresters on the hot and cold lines.

Laing Thermotech ACT-4 Specifications

General

Brand	Laing Thermotech
Model	ACT-4
Category	Plumbing Product
Language	English

Summary

Introduction and Safety

Introduction and Purpose

Explains the manual's goal and provides a brief overview of the product.

Safety Terminology and Symbols

Defines safety terms, hazard levels, and explains safety symbols used in the manual.

General Safety Precautions

Outlines critical safety warnings, cautions, and notices for safe operation and maintenance.

User Safety Rules and Equipment

Details user safety rules, required equipment, and environmental protection measures.

Electrical Safety and Precautions

Discusses electrical connections, precautions before work, and procedures for skin/eye contact.

Environmental Safety and Waste

Addresses environmental safety, keeping the work area clean, and waste/emissions regulations.

Compliance and Certifications

Includes FCC statement for U.S. users and CSA certification details.

Product Description

Product Overview and Benefits

Introduces the ACT-4 wireless kit, its features, and advantages for users.

Kit Contents and Requirements

Lists all items included in the kit and additional parts needed for installation.

System Operation and Specifications

Explains how the system works and provides key operational limits and performance data.

Installation Guide

Preinstallation and Preparation

Covers essential safety checks and preparation steps before beginning installation.

Recommended Installation Diagram

Provides a visual guide for setting up the system components during installation.

Pump Installation Procedure

Step-by-step instructions for correctly installing the ACT-4 wireless pump.

Valve Installation Procedure

Step-by-step instructions for correctly installing the ACT-4 wireless mixing valve.

Operation and Controls

Thermostat and Timer Operation

Guides on setting the thermostat and programming the timer for optimal hot water circulation.

Optional Push-Button/Repeater Usage

Instructions for adding and utilizing the optional push-button or signal repeater device.

Maintenance and Troubleshooting

Routine Maintenance Checks

Covers periodic inspection, battery replacement, and returning the system to service.

Device Pairing and Troubleshooting

Details device pairing after replacement and provides solutions for common operational issues.

LED Status Codes and Operation Issues

Provides a guide to LED indicator lights and common operational problems with remedies.
