3
Exclusive to Howdens
820 - 920mm
(890mm Howdens
standard install)
min
575mm
600mm
(+2mm)
Position the appliance relative to service
connections.
Prepare cabinet niche
It is critical that
the appliance is
installed level.
Worktop
WARNING!
Appliance must be
earthed. Socket must
be accessible after fitting.
WARNING!
Do not use extension
cable or adapters.
Note: For profile kitchens -
insert 18mm board below
worktop, level with bottom
edge of front panel.
If opening against a wall, 180mm
clearance is required to allow
the baskets to be removed.
180mm
180mm
