Lamona LAM8720 Installation Instructions

7
Exclusive to Howdens
REMOVE
CAP/END
*
max.
100mm
min
500mm
min
300mm
max
1000mm
min
500mm
min
300mm
max
1000mm
All dimensions are to the floor.
*
DO NOT insert the hose too deep into the waste pipe,
(Maximum hose length, 3.2 metres).
6 - Washing machine connections
WARNING! This appliance
must be earthed.
(Socket must be accessible
after fitting).
Ensure cap/end is removed from
waste pipe spigot.
WARNING! Do not use extension
cables / adapters.
Ensure water is turned on and
the isolator valve is accessible
after fitting.
Hose connection - 3/4”.
Cold water pressure -
0.3 –10 bar (0.03-1.0 Mpa)
NOTE: If necessary loosen and
rotate the water hose towards
the water supply and re-tighten.
(Always use the new hose
supplied with the washing
machine).
Cold water supply
10-80 lpm.
DO NOT KINK HOSES
BEHIND MACHINE!
Machine will not work properly.
12921 LAM8720_40 WM_INSTALLATION.indd 712921 LAM8720_40 WM_INSTALLATION.indd 7 04/11/2020 11:18:4704/11/2020 11:18:47

Lamona LAM8720 Specifications

General

Style	Front-Loading
Color	White
Washer Capacity	7 kg
Dryer Capactity	-
Max Spin Speed	1200 RPM
Spin Speeds	-
Spin Class	B
Number of Cycles	15
Cycle Selections	Drain + Spin
Wash	Delicates(Hand Wash)
Options	End of Cycle Signal
No spin and No heat	Extra Rinse
Hours	WashSense Technology
Noise level	71 dB
Temperature Selections	6
Cold)	Tap Cold (All Cold Rinses))
Energy Class	C
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	41 L
Voltage	230V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	560 mm
Height	820 mm
Width	600 mm
Net Weight	71 kg
