13
32 VIDEO FRAME RATE (25/30)
Selects the video standard being used, in frames per second. For NTSC, 525/60
SDI, and any high-def formats that use 30 frames/sec, or 29.97 frames/sec set this
item to ‘30’. For PAL, 625/25 SDI or other 25 frame/sec standards, select ‘25’. This
setting must match the video frame rate being used in the ddrs. The controller will
operate with the wrong standard selected, but all time calculations will be wrong, and
confusing things will happen.
There are two more items which may be selected in the menu. These are not menu
items, but are just information displays (they can’t be set by the users).
DEVICE: Displays the type of controlled device, to the extent that the TDC can
determine it. If a Profile or Fast Forward is in ‘BVW’ mode, this item will identify
them as ‘Sony VTR’. If they are in Non-BVW modes, the TDC will try to report what
protocol is selected. The frame rate of the controlled device will also be displayed.
TDC FIRMWARE VERSION: Displays the installed firmware in the TDC frame.
This manual applies to version 3.4 firmware.
With the exception of the Status Check items which are always turned on at power-
up, and the Pbus Data Display, which is always turned off, all menu items are
retained in non-volatile memory and will not change when the controller is turned off.
