20
TBC CONTROL WITH THE TDC-100
The TDC-100 can control VTR/Disk TBC or output video processor levels and
timing. This is possible only for vtrs or disk recorders which allow these levels to be
controlled via the standard RS-422 machine control port, via the standard Sony
protocol.
Machines which allow this include: Panasonic AJ-D350
AJ-D351
AJ-D360
AJ-D580
DVC PRO
Sony DVR-10
DVR-18
DVR-20
DVR-28
DVW-500
IMX VTRs
MAV-555
Any Sony VTR equipped with
Lance Design AIF-422 adapter
Drastic Technologies VVCR Disk
Fast Forward Omega (timing only)
To access this control, just select the device that you want to adjust, and press and
release the ‘FCN’ button, then press the ‘Menu’ button. Select the parameter that
you want by using the ‘+’ and ‘-’ keys on the keypad to scroll through the functions.
If there is no number displayed after the parameter label, then the selected device
does not support this control protocol.
Levels are adjusted with the jog knob, and may be set to UNITY by pressing the
“CLR’ (clear) button on the keypad. This sets only the selected parameter to unity.
This level adjustment data is stored in the device, not in the panel, so that there is no
need to re-set levels if machine assignments are changed.
