SAFETY
161
2
SIDE AIRBAGS
(Side bag - Window bag)
SIDE BAG fig. 10
This consists of an instant-inflating cushion housed in the
front seat backrest. It protects the chest and the hips of
the passengers in the event of a side impact of medium-
high severity.
WINDOW BAGS fig. 11
These consist of two “drop-down” bags housed behind the
side upholstery of the roof and covered with finishing el-
ements, which protect the heads of front and rear pas-
sengers in the event of a side impact thanks to a wide bag
deployment area.
IMPORTANT In the event of a side crash, the system pro-
vides best protection if the passenger sits on the seat in a
correct position, thus allowing correct window bag de-
ployment.
fig. 10
L0E0070m
fig. 11
L0E0071m
