260
The differential ratios are:
BRAKES
SERVICE AND EMERGENCY
BRAKES
Front: disc brakes with floating
shoes and one cylinder per wheel.
Rear: disc brakes with floating shoe
Crossed hydraulic circuit control.
8" vacuum brake booster with addi-
tional chamber (1.6 - 1.8 and 1.9 jtd
versions). 7" + 8" double tandem
vacuum brake booster (2.0 and 2.4
jtd versions).
Four sensor, four channel ABS.
Automatic take-up of friction liner
wear.
Brake force distributor governed by
the ABS system.
HANDBRAKE
Controlled by a lever, it works me-
chanically on the rear brakes.
DIFFERENTIAL
Final drive gear and differential as-
sembly built into the gearbox.
Drive transmission to the front
wheels by means of drive shafts con-
nected to the differential and to the
wheels with CV joints.
Final reduction Number
differential torque of teeth
1.6 3,823 65/17
1.8 3,733 56/15
2.0 3,733 56/15
1.9 jtd 3,353 57/17
2.4 jtd 3,111 56/18
