Lancol MICRO-500 - How to Use; Connection; Battery Test Procedure

3
5. Housing Material：Acid-resistant ABS plastic
6. The length of testing cables: 55cm
Main functions:
1
BATTERY TEST
2
CRANKING TEST
3
CHARGING TEST
4 REVIEW DATA
5 LANGUAGES
6 HELP
How to use:
1. CONNECTION
Connect the red test clamp with positive electrode and the black one with
negative electrode, the tester will power on automatically. Voltage battery
below 7.0VDC can’t be tested properly, then press ENTER key to continue.
Connect clamps to battery electrode Tester power on automatically
Notes: Voltage over 30V will damage the tester .
2. BATTERY TEST
a).Select the charge sate b). Select battery type
