Landmann BALL 'O FIRE - Parts List

PARTS LIST:
When unpacking the Ball 'O Fire from the carton, make sure you find and become familiar with all the pieces listed below:
VER. 1, 8/22/07
C
(3) LEGS
P
(26)
M6 x 13
BOLTS
(1) COVER
(1) CENTER RING
E F
G
A B
(3) BOTTOM
SCREEN
SECTIONS
(3) BOTTOM
SCREEN
SECTIONS
(1) LEFT FIXED
TOP SECTION
(1) CENTER FIXED
TOP SECTION
(1) RIGHT FIXED
TOP SECTION
H
J
K
(1) LEFT DOOR
SECTION
(1) CENTER DOOR
SECTION
(1) RIGHT DOOR
SECTION
L
M N
(1) CONNECTING
RING
(1) CONNECTING
RING W/ HANDLE
(2) BOWL
HANDLES
Q
O
(1) BOWL
UT
S
(6)
M6 x 10
BOLTS
(6)
M6 x 20
BOLTS
R
(6)
M6 x 25
BOLTS
X
(6)
M6
CAP NUTS
V
(2)
M6 x 40
BOLTS
Y
(2)
LOCK
WASHERS
W
(48)
M6
HEXNUTS
PAGE 2
BALL 'O FIRE
™
IF YOU HAVE MISSING
OR DEFECTIVE PARTS,
PLEASE CALL CUSTOMER
SERVICE AT 1-877-347-4557
FOR OUTDOOR
USE ONLY
!
